Case Studies

AN INTERESTING CASE OF COCHLEAR IMPLANT AND MAGNET CHANGE

0.5
0.5

press to zoom
1
1

press to zoom
17
17

press to zoom
0.5
0.5

press to zoom
1/20

Despite the more recent and advanced cochlear implants being quite compatible with MRI, it is not unusual to come across complications during scanning such as partial or complete depolarization of the magnet, displacement of the implant electrode and pain, where the scan needs to be abandoned. Nevertheless, the disrupted implant needs to be addressed to put the implant back to its function.

Here we have an experience to share, where a child, having previously undergone cochlear implantation for her right ear, at a private center, was planned for left ear cochlear implantation at our center. Owing to the dilemma of the patient not being offered a simultaneous bilateral cochlear implantation during the first time, and lack of any previous medical reports, radiological images, the patient again had to be worked up. During the 1.5 tesla MRI scan, the child complained of severe, lancinating pain over her right temporal region during the scan. Following this, the processor was found to be dysfunctional and wouldn’t sustain in place, suggesting either magnet displacement or depolarization which rendered the child bilaterally deaf. One of the options was to install a reverse polarized magnet in the processor. Since the arrival of the magnet would have taken more than a couple of weeks, the child was planned for cochlear implantation on the left side without delay, along with exploration of the receiver stimulator bed of the existing implant on the right side.

The receiver stimulator bed on the right was approached a little posteriorly lest not to end up damaging the receiver while dissecting the soft tissue. The button magnet of the stimulator was found flipped over its belly, which was retrieved from its pocket. The magnet was also weak, suggesting depolarization, hence a new magnet was replaced in its place, and wound closed in layers. The cochlear implantation was completed uneventfully on the opposite side as planned.

OSIA IMPLANTATION

1
1

press to zoom
2
2

press to zoom
16
16

press to zoom
1
1

press to zoom
1/16

Osia, the world’s first Osseointegrated steady state implant, is a piezoelectric mechanism, unlike a conventional BAHA implant, giving the nearest possible experience of natural hearing. With all its components- the bone anchoring implant, the actuator and the electromagnetic coil placed underneath the skin, unlike as it is in a conventional BAHA, where the bone implant with its abutment fixture needs to be punctured out through the skin and the processor unit exteriorized completely, Osia is much concise yet sophisticated.

This week, we have a middle-aged male, who was earlier diagnosed with right otosclerosis and underwent a stapedotomy with Teflon piston insertion, with some improvement in his hearing. No sooner than 3 months after surgery, he developed acute severe mixed hearing loss, on the operated side without any other significant medical history. The patient underwent a revision stapedectomy again 7 months later, without any improvement in his hearing.

The patient was operated at Bangalore Skull Base Institute - Bangalore Hearing and Implant Institute by Team Dr. Sampath Chandra Prasad Rao and he underwent Osia ‘Cochlear OSI200’ implantation under general anesthesia, in a post auricular approach with extension if the skin incision into the suboccipital area. The conical guide drill is placed on the identified area of the skull which is relatively flat behind the ear, and the hole is widened with countersink drill bits. The bone bed is then levelled and prepared with a bone bed indicator. The implant with the coil and actuator is then positioned and secured over the ‘Cochlear BI300’ implant with the fixation screw. Hemostasis is then secured and wound closed in layers

Bilateral Cochlear Implantation

1
1

press to zoom
2
2

press to zoom
19
19

press to zoom
1
1

press to zoom
1/18

Proven  and agreed upon are the advantages of an early bilateral cochlear implant over  being done on only one side, specifically for the better speech and language learning capabilities and unarguably better binaural sound perception, not to mention the enhanced brain and intellectual development of a born deaf individual. With an incidence of nearly 5700 cases for every million newborn children, congenital deafness bears a significant impact on our developing society, be it both economically and emotionally. This week's  case of a week is about a one and a half year old baby born with bilateral severe to profound hearing loss, who underwent a successful simultaneous bilateral cochlear implantation.
The psychomotor evaluation of the child preoperatively was satisfactory for her age. The radiological- HRCT temporal bones showed favorable anatomy and MRI was suggestive of bilateral normal morphology.
The procedure was posterior tympanotomy facial recess approach with extended cochleostomy on both the sides, the implants used were 'Nucleus profile plus with slim modular electrode CI632', the insertion of the electrode arrays complete and smooth. The procedures on both sides were uneventful.  The post operative HRCT temporal bones done on POD-I confirmed the position of the implants.

A tale of epistaxis : case of capillary hemangioma of temporal bone

1
1

press to zoom
3
3

press to zoom
28
28

press to zoom
1
1

press to zoom
1/52

A 48-year-old male patient from Bangladesh presented with epistaxis. Multiple investigations including endoscopy and radiological evaluation confirmed the primary source of bleed as a mass lesion involving the left temporal bone and eustachian tube. His Pure Tone Audiometry revealed hearing sensitivity within normal limits in the right ear and moderate mixed hearing loss in the left ear.
The patient underwent Subtotal Petrosectomy with blind sac closure with ipsilateral BI 300 4mm implant with abutment. Post-operative recovery was uneventful. Histopathology revealed the lesion to be a capillary hemangioma.  Four weeks after the surgery the patient was fitted with Baha 5 Power processor.

Bilateral Cochlear Implantation

1
1

press to zoom
2
2

press to zoom
33
33

press to zoom
1
1

press to zoom
1/34

A 14-month-old baby boy from Bangalore was diagnosed with congenital bilateral sensorineural hearing loss. BERA revealed bilateral severe-to-profound hearing loss. Baby was fitted with hearing aids on both the sides and was given auditory verbal therapy for a period of 3 months. There were no benefits seen using the same. Hence, he was recommended to undergo bilateral cochlear implant surgery. CT & MRI revealed no anatomical abnormality on both the sides. Bilateral Cochlear Implantation was performed with Cochlear Nucleus CI632 Implant. Intra-operative monitoring revealed Impedance and Neural response telemetry within normal limits (NRT).

Translabyrinthine approach for Giant Vestibular schwannoma with simultaneous Ipsilateral Osia implantation for hearing restoration

press to zoom

press to zoom

press to zoom

press to zoom
1/29

A 51-year-old male patient presented with a one-year long history of nausea, vomiting and imbalance. The episode got precipitated following a minor RTA, and was associated with gradual loss of hearing with poor speech discrimination and tinnitus in the left side. MRI revealed a heterogeneously enhancing solid tumor of 3.69cmX2.99cmX3.52cm size with cystic areas in the left CPA. The tumor was seen widening the fundus of left IAM, which is a feature highly suggestive of vestibular schwannoma. A Translabyrinthine approach for excision of giant Vestibular Schwannoma was performed with simultaneous ipsilateral OSIA Implantation for hearing restoration. Post-surgery patient recovered well with a HB grade II facial paralysis. Upon switch on of the OSIA implant, the patient was able to hear normally with good speech discrimination, in both quiet and noisy environment.

Skull Base Osteomyelitis with ipsilateral Cochlear Implantation

Copy of 8A
Copy of 8A

press to zoom
Pre Op Pictures
Pre Op Pictures

press to zoom
Post Op Pictures
Post Op Pictures

press to zoom
Copy of 8A
Copy of 8A

press to zoom
1/22

Skull base osteomyelitis due to impacted foreign body in the petrous bone: Subtotal petrosectomy with facial nerve decompression with simultaneous ipsilateral cochlear implantation for hearing restoration



A 56 year old lady presented with right ear pain, ear discharge, bleeding and facial deviation for 1 month. Patient had a past history of severe hearing loss for several years and was offered hearing aid. During the trial, ear mould was inserted deep inside the EAC following which she developed symptoms. A week later she developed facial paralysis, following which a local ENT surgeon removed ear mould debris from the EAC and referred the patient to our center. Otoendoscopy revealed large central perforation with mucopurulent discharge and granulations in the EAC. Patient had HB Grade V facial nerve paralysis. Pure tone audiometry revealed profound hearing loss 90dB in the right ear and 75dB severe SNHL in the left ear. HRCT temporal bone revealed soft tissue density in the middle ear and EAC with demineralization of the tympanic segment of the facial nerve with ? foreign body along the horizontal petrous carotid and eustachian tube. Patient underwent Subtotal petrosectomy with facial nerve decompression with simultaneous ipsilateral cochlear implantation for hearing restoration. The foreign body which was an ear mould material was removed completely. Post surgery, recovery was uneventful. She was put on long term antibiotics as per our SBO antibiotic protocol. The CI switch on was done after 3 weeks, following which the patient’s hearing has been restored successfully. Over 3 months, her facial nerve function has marginally improved and it is expected to improve further.

CPA Epidermoid with ipsilateral BI300 implant

img#268
img#268

press to zoom
CPA Epidermoid
CPA Epidermoid

22 years old male patient presented with intermittent episodes of giddiness and tinnitus left ear with left ear block since six months. Otoendoscopy revealed intact TM. VII, IX, X, XI, XII cranial nerve examination was normal. Pure tone audiometry revealed bilateral hearing sensitivity within normal limits. MRI Brain and temporal bone with contrast showed well defined non-enhancing T1 hypointense and T2 predominant hyperintense diffusion restricting lesion in the left CPA suggestive...

press to zoom
CPA Epidermoid
CPA Epidermoid

22 years old male patient presented with intermittent episodes of giddiness and tinnitus left ear with left ear block since six months. Otoendoscopy revealed intact TM. VII, IX, X, XI, XII cranial nerve examination was normal. Pure tone audiometry revealed bilateral hearing sensitivity within normal limits. MRI Brain and temporal bone with contrast showed well defined non-enhancing T1 hypointense and T2 predominant hyperintense diffusion restricting lesion in the left CPA suggestive....

press to zoom
img#268
img#268

press to zoom
1/26

A 22 years old male patient presented with intermittent episodes of giddiness, tinnitus and blockage in the left ear for six months. Otoendoscopy revealed intact TM. VII, IX, X, XI, XII cranial nerve examination was normal. Pure tone audiometry revealed bilateral hearing sensitivity within normal limits. MRI Brain and temporal bone with contrast showed well defined non-enhancing T1 hypointense and T2 predominant hyperintense diffusion restricting lesion in the  left CPA, suggestive of an epidermoid (22x27x22mm). Translabyrinthine approach for the excision of the CPA epidermoid with blind sac closure and BI300 4mm implant was placed on the mastoid occipital region. Postoperatively, the patient had HB grade II facial nerve paralysis with no intracranial complications. Histopathology was consistent with epidermoid.

Temporal Bone Squamous Cell Carcinoma with ipsilateral BI300 implant

Temporal Bone Squamous Cell Carcinoma
Temporal Bone Squamous Cell Carcinoma

A 74 year male, known diabetic, presented from Mysore, with blood tinged left ear discharge and ear pain since one month. Patient had a long standing history of bilateral ear discharge, decreased hearing left ear more than the right and occasional giddiness on and off since 20 years. There was no history of facial nerve paralysis. He was on oral antibiotics, analgesics on and off for the same. Otoendoscopy revealed left EAC aural polyp obscuring the view of Tympanic membrane, right ear showed...

press to zoom
Temporal Bone Squamous Cell Carcinoma
Temporal Bone Squamous Cell Carcinoma

A 74 year male, known diabetic, presented from Mysore, with blood tinged left ear discharge and ear pain since one month. Patient had a long standing history of bilateral ear discharge, decreased hearing left ear more than the right and occasional giddiness on and off since 20 years. There was no history of facial nerve paralysis. He was on oral antibiotics, analgesics on and off for the same. Otoendoscopy revealed left EAC aural polyp obscuring the view of Tympanic membrane, right ear showed...

press to zoom
Temporal Bone Squamous Cell Carcinoma
Temporal Bone Squamous Cell Carcinoma

A 74 year male, known diabetic, presented from Mysore, with blood tinged left ear discharge and ear pain since one month. Patient had a long standing history of bilateral ear discharge, decreased hearing left ear more than the right and occasional giddiness on and off since 20 years. There was no history of facial nerve paralysis. He was on oral antibiotics, analgesics on and off for the same. Otoendoscopy revealed left EAC aural polyp obscuring the view of Tympanic membrane, right ear showed...

press to zoom
Temporal Bone Squamous Cell Carcinoma
Temporal Bone Squamous Cell Carcinoma

A 74 year male, known diabetic, presented from Mysore, with blood tinged left ear discharge and ear pain since one month. Patient had a long standing history of bilateral ear discharge, decreased hearing left ear more than the right and occasional giddiness on and off since 20 years. There was no history of facial nerve paralysis. He was on oral antibiotics, analgesics on and off for the same. Otoendoscopy revealed left EAC aural polyp obscuring the view of Tympanic membrane, right ear showed...

press to zoom
1/3

A 74 year male, known diabetic, presented with blood tinged left ear discharge and ear pain since one month. Patient had a long standing history of bilateral ear discharge, decreased hearing left ear more than the right and occasional giddiness on and off since 20 years. There was no history of facial nerve paralysis. He was on oral antibiotics, analgesics on and off for the same. Otoendoscopy revealed left EAC aural polyp obscuring the view of Tympanic membrane, right ear showed subtotal perforation with edematous middle ear mucosa. There were no palpable neck nodes. Cranial nerve examination including Facial Nerve was found to be normal. Biopsy of the aural polyp revealed moderately differentiated squamous cell carcinoma. PTA showed profound hearing loss in the left ear (>90 dB) and severe sloping mixed hearing loss in the right ear (85dB). Subtotal temporal bone resection with selective (level V, IIA, IIB) neck dissection and partial parotidectomy with blind sac closure was performed. BI300 4mm implant with cover screw placed on the mastoid occipital bone. Post op Facial nerve status was HB Grade II. Patient is planned for radiotherapy.
